MenaceRC Goggle Pack
The Menace FPV Goggle Pack includes their smallest patch paired with their tallest omni antennas to get you the best experience in FPV straight out of the box.
Take the guess work out of selecting your goggle receiving antenna’s and use this proven combination of patch and omni over the head matched pair.
The PICOpatch antenna is a tiny receiving patch but it's big in performance.
The Periscope Antenna gets the active part of the antenna above your head for clearer signal for not only flying behind yourself but in all directions.
If your starting out or looking to upgrade your FPV setup then the Goggle Pack is for you.
Specs:
Pico Patch
Frequency Range: 5645 – 5945 Mhz
Gain: 9.4 dBi
Beam Width: 61° at -3db points
(Check polar plot comparison invader actual angular db)
Left or Right Hand Circular Polarised (LHCP or RHCP)
SMA Connector (Fits Fatshark Goggles)
Dimensions: 37.0mm x 33.6mm x 19.2mm
Weight: 10 grams
Periscope:
Centre frequency 5.8 GHz
Frequency Range: 5550 – 6050 MHz
Matching S11 < -20dB, VSWR <1.22
Gain: 1.09dB with efficiency: 92%
Axial Ratio <1.3
Beam width: 360 degrees
Left or Right Hand Circular Polarised ( LHCP or RHCP)
SMA 90 Degree Connector
Height: 138mm
Weight: 14grams
Includes:
1x Pico Patch Antenna
1x Periscope Omni Antenna
2x SMA finger spinners
