Runcam Phoenix 2 Nano

Regular price £25.90
Regular price Sale price £25.90
Shipping calculated at checkout.

Runcam have squeezed the same image sensor as the full size Phoenix 2 into this 14mm nano version. So you still get the 1/2" image sensor and f/2.0 aperture, M8 mounting, lens that enable it to produce vivid high resolution pictures. It has a super clear 1000TVL image that displays excellently in daylight as well as low light.

You can also easily switch between PAL and NTSC and  4:3/16:9 aspect ration.


Image Sensor: 1/2" WDR CMOS Sensor
Horizontal Resolution: 1000TVL
Aspect Ratio: 4:3 / 16:9
Signal System: PAL / NTSC
Lens Size: M8
Focal Length: 2.1mm
Field of View: 155° (4:3)
Minimum Illumination: 0.01Lux @ 1.2F
Signal to Noise Ratio: >50dB (AGC OFF)
Input Voltage: 5-36V
Current Draw: 190mA@5V, 85mA@12V
Housing Material: ABS
Dimensions: 14x14x22mm (Nano)
Weight: 5g


1x Runcam Phoenix 2 Nano FPV Camera
1x ABS 19mm adapter bracket
1x Set of screws
1x 5 pin FPV Silicone Cable
